Simagic M10 Dash Board
Simagic M10 Sim Dash Board and Button Box
The Simagic M10 Sim Dash Board is an excellent addition to enhance your sim racing experience. Although the manufacturer has discontinued this wheelbase, we still offer this Dash Board on a lead time of 2-4 weeks. Designed specifically for PC setups. It connects via a single USB cable (6ft USB cable included) and is plug-and-play—no additional software required.
Compatibility:
Please confirm that the Simagic M10 Sim Dash Board fits your setup. Additionally, the dash has enclosures and cables at the rear, which may not suit certain mounts and might require spacers. If you are unsure, please contact us for assistance to ensure the Sim Dash Board will work with your rig.
Features:
- 6mm Real Carbon Fiber Matte Twill Weave Plate
-
Left Side:
- 1 On-Off Latching Toggle with Guard (PROGRAMMED AS MOMENTARY)
- 1 Apex Branded Engine Start Button
- 3 MOM OFF MOM Toggles with black boot
- 5 12mm Momentary Push Buttons (Optional 7-way multi-switch replaces center push button) - Up, Down, Left, Right, Push, Encoder Left & Right
-
Right Side:
- 8 12mm Momentary Push Buttons
- 4 CTS Encoders
- 1 Billet Aluminum Brake Bias Knob (can be used for other settings)
Mounting:
The Simagic M10 Sim Dash Board includes left and right side mounts with hardware. Additionally, it uses slots on the side of the wheelbase for easy installation.
Dimensions:
- Dash Size: W 24" x H 4.5" x D 1.5" (see the drawing in the photos section)
EMI Note for Fanatec Wheelbases:
Some customers have reported EMI from Fanatec wheelbases. Therefore, if you experience button press issues with your Simagic M10 Sim Dash Board, you may need to ground the dash to the wheelbase using the provided wire. To resolve this, please follow these steps:
- First, remove the rear enclosure plate with a 2mm Allen Key.
- Next, strip about 1 inch off the provided wire, route it to the wheelbase, and wrap it around the M6 bolt between the rear of the Sim Dash Board and the front of the wheelbase (as shown in the image).
- Then, mount the dash as normal with the wire positioned between the carbon plate and the wheelbase.
Fanatec Podium Ground Wire EMI:
Finally, refer to the diagram for grounding instructions. Right-click and open the image in a new tab or save it to see it in full size.
